M Series
Standards and Specifications Table
| Models | MOC-16 | MOC-20 |
|---|
| Moisture evaporation volume | 21kg/h 28kg/h※1 | 35kg/h 48kg/h※1 |
|---|
Moisture evaporation capacity values when operating at a hot air temperature of 250ºC and a discharge air temperature of 100ºC.
*1 moisture evaporation capacity values are when operating at a hot air temperature of 300ºC and a discharge air temperature of 100ºC.
List of Functions
| Features |
For the M Series, we kept the popular convenience and detergency advantages of the F Series and added the following features to meet new demands.
1. Improved contamination prevention
■ Added a medium performance filter to the course dust filter on the suction filter as standard equipment.
■ Just as with the F Series a high performance hot air filter comes standard.
2. Handling of small particles
■ Changed the cone of the drying chamber to improve main unit cone small particle powder deposition.
■ Adopted a take-up method that takes duct curved section wear and detergency due to small particle powders into consideration.
3. Better performing bag filter
■ Introduced a bag filter with greater excess area to reduce filter clogging. |
| Applications |
Ceramics/Other |
| Industries |
Electronics industry/Vehicle industry/Ceramics industry and fine ceramics/Steel and machinery industries/Other |
| Specifications |
Heat source (electric heater)
Atomizing method (rotary disc)
Product recovery method (main unit, cyclone dual-point collection)
|
| Remarks |
Moisture evaporation volume: 21 to 48 kg/h |
*1: Heat source standard specifications vary based on model.
*2: Can be used as an optional extra.
